EXODUS High Broadband Amplifier Modules 500MHz-18GHz

Exodus Advanced Communications High Broadband Frequency HPA High Power Solid State Power Amplifiers Header

Exodus Advanced Communications High Broadband Frequency HPA (High Power Solid State Power Amplifier Modules) 500MHz~18GHz

Exodus Broadband SSPA (Solid Sate Power Amplifiers) products feature LDMOS, GaN, GaAsFET discrete and Chip & Wire Hybrid technologies covering one octave through decades frequency ranges from 500MHz to 18GHz at power levels exceeding 300W for Modules and 500W for Systems.


MODEL

 MIN
FREQUENCY
(MHz)

 MAX
FREQUENCY
(MHz)

OUTPUT
(W or dBm)

GAIN
(dB)

Source
(Volt)

DATA
SHEET

AMP1074-4

700

18000

5

37

32

pdf

AMP1010

800

4200

100

50

32

pdf

AMP1082

1000

20000

5

37

22-24

pdf

AMP1083

1000

8000

6

38

15

pdf

AMP1123

1000

20000

6

38

28

pdf

AMP1077

2000

18000

5

37

32

pdf

AMP1029

2000

6000

50

47

28-30

pdf

AMP1070

2000

18000

30

45

32

pdf

AMP1071

2000

20000

20

43

32

pdf

AMP1074-2

2000

18000

8

40

32

pdf

AMP1074

2000

20000

10

40

32

pdf

AMP1141

2000

20000

5

37

22

pdf

AMP1123-1

2000

18000

5

38

28

pdf

AMP1074-5

2000

18000

10

40

28-32

pdf

AMP1074-6

2000

12000

10

40

32

pdf

AMP1071-1

2000

12000

20

43

32

pdf

AMP1074-1

3000

14000

10

40

32

pdf

AMP1144

4000

12000

5

37

22-24

pdf

AMP1094

4000

18000

20

43

32

pdf

AMP1095

4000

18000

30

46

32

pdf

AMP1077-1

4000

12000

5

37

32

pdf

AMP1074-3

4000

18000

10

45

32

pdf

AMP1082-4

4000

12000

2

33

22-24

pdf

AMP1082-1

5000

11000

5

37

22-24

pdf

AMP1065

6000

12000

40

46

30

pdf

AMP1057

6000

12000

5

37

32

pdf

AMP1068

6000

18000

10

40

12

pdf

AMP1062

6000

18000

40

46

32

pdf

AMP1052

6000

18000

20

43

12

pdf

AMP1059

6000

12000

20

43

32

pdf

MODEL

 MIN
FREQUENCY
(MHz)

 MAX
FREQUENCY
(MHz)

OUTPUT
(W or dBm)

GAIN
(dB)

Source
(Volt)

DATA
SHEET

AMP1072

6000

18000

30

45

32

pdf

AMP1058

6000

12000

10

40

28-30

pdf

AMP1069

6000

20000

20

43

32

pdf

AMP1079

6000

18000

5

37

12

pdf

AMP1111

6000

18000

7

37

32

pdf

AMP1068-1

6000

18000

12

42

32

pdf

AMP1121

6000

18000

30

45

12

pdf

AMP3105

6000

10000

40

46

32

pdf

AMP1068-3

6000

18000

8

40

12

pdf

AMP1122

6000

18000

60

48

32

pdf

AMP1068A

6000

18000

12

42

32

pdf

AMP1052A

6000

18000

20

43

32

pdf

AMP1122A

6000

18000

100

50

32

pdf

AMP1068BH

6000

18000

18

42

12

pdf

AMP1122BH

6000

18000

100

50

32

pdf

AMP1062A

6000

18000

50

47

32

pdf

AMP1062BH

6000

18000

50

47

32

pdf

AMP1052BH

6000

18000

30

45

32

pdf

AMP1062ALW

6000

18000

40

46

32

pdf

AMP3074

6725

7025

100

60

12

pdf

AMP3080AP

7500

10000

500

57

30

pdf

AMP3039

7600

9600

40

46

40

pdf

AMP3079

8000

12000

25

44

30

pdf

AMP3026

8000

12000

50

47

30

pdf

AMP3085

8000

12000

100

50

32

pdf

AMP1062-1

8000

18000

40

46

32

pdf

AMP3063-1P

8000

10000

500

57

42

pdf

AMP1082-5

8000

12000

5

33

22-24

pdf

AMP3125

8000

9000

100

50

40

pdf

AMP3063P

8000

10000

1000

60

42

pdf

MODEL

 MIN
FREQUENCY
(MHz)

 MAX
FREQUENCY
(MHz)

OUTPUT
(W or dBm)

GAIN
(dB)

Source
(Volt)

DATA
SHEET

AMP1062A-1

8000

18000

50

47

32

pdf

AMP5010

8175

8210

400

56

40-42

pdf

AMP3013

8500

10500

20

43

27.5-28.5

pdf

AMP3004P

9100

9500

400

56

49

pdf

AMP3008

9100

10100

20

43

27.5-28.5

pdf

AMP3040

9100

10100

4

30

12

pdf

AMP5022-1

9300

9700

50

47

40

pdf

AMP3009P

9500

10500

300

50

40

pdf

AMP3009-1-2

9500

10500

100

50

40

pdf

AMP5022

10000

10000

40

12

32

pdf

AMP3106

10000

18000

13

43

12

pdf

AMP3107

10000

18000

40

46

12

pdf

AMP5040

10000

10000

25

44

40

pdf

AMP3103

10500

12750

40

46

32

pdf

AMP5045P-A-B

11300

18000

10

40

40

pdf

AMP5046P-A-B

11300

18000

100

50

40

pdf

AMP5007

11424

11424

120

50

48

pdf

AMP3088

12000

14000

7

38

12

pdf

AMP5053

12000

13000

20

43

20/40

pdf

AMP5014

12600

12600

100

50

42

pdf

AMP5060

13450

13850

10

30

40

pdf

AMP5034

14000

14500

40

50

40

pdf

AMP1068A-1

14000

18000

15

42

32

pdf

AMP5034-1

14400

14830

20

43

28

pdf

AMP3022-1

15000

18000

40

46

42

pdf

AMP3022-2

15000

18000

20

46

42

pdf

AMP3022-3

15500

16500

6

38

28

pdf

AMP5008

15750

15750

100

50

42

pdf

AMP3042

16200

16500

30

45

42

pdf

AMP5056

17700

18300

5

37

12

pdf
